Weather data mobile tracking system

METEOTRACKER ELEMENTS

meteotracker sample data

MeteoTracker is a low-costhigh-accuracy system for mobile acquisition and tracking of weather data, potentially transforming any vehicle in a traveling weather station. MeteoTracker consists of a multi-sensor to be installed externally on a vehicle, an APP mobile and a WEB platform and performs spatially continuous weather data acquisition, addressing the severe limitation of the standard fixed weather stations network, whose spatial undersampling does not allow the even more demanded high-resolution weather and climate characterization.

WHAT IS METEOTRACKER

METEOTRACKER USE-CASES

MeteoTracker is currently completing the field-test phase and several hundreds thousand of weather-points have already been collected. Temperature variation ratios as strong as 8.4° over 400 m distance (South-East Sardinia, July 7th 2019) and 5.7° over 280 m distance (Munich region, April 21st) and other very interesting hyper-local effect (see and river breeze, strong adiabatic temperature shift from on mountain side to the other, etc...) have been measured.

Road-management, energy management, smart-city, meteorological research, drone-based weather data collection are some of the possible fields where MeteoTracker can provide an important source of weather knwoledge.

And everyone interested in weather data can seamlessly turn every road-trip into an accurate MeteoTracking

The MeteoTracker multi-sensor

MULTI-SENSOR



Compact and light, instantly installed externally to a veichle by magnets, the MT multi-sensor allows very fast and accurate measurements thanks to a patent-pending system for solar radiation error correction, based on a differential approach to air temperature measurement.

APP



The MT APP collects and geo-tags weather-data acquired every x meter (x ranging from 1 m to 200 m, according to user preferences) and sends them to the cloud, while real-time visualized on the smartphone display.  Also, the MT APP performs archive management and visualization by advanced map and graph based tools.

gallery/moto with_mt_app

WEB PLATFORM



The MT WEB platform manages the database operations and provides the user with an easy-to-use front-end interface for real-time/archive data visualization. Advanced tools for map/graph-based analysis give the user a complete set for maximazing the value extraction from MT personal and pubblic data collection.

gallery/grafrath_moorenweise_all
gallery/composite
gallery/graph_map_ca_pula_20190913
gallery/donau_deggendorf_june_2019_composite

SOUTH-EAST SARDINIA (ITALY), STRONG TEMPERATURE VARIATION RATIO (8.4° IN 400 M DISTANCE, JULY 7TH, 2019

The MeteoTracker multi-sensor is featured with a patent-pending system for preserve hugh-accuracy even under strong solar radiation while keeping sensins elements full exposure to ventilation in order to get very fast measurement time, which is essential to correctly mapping the thermal profile of a parameter, like air-temperature, that may have very high spatial variation ratio.

MeteoTracker measured up to 9° of variation over a distance less than 400 m .

Realt-time visualization, both on map and Street View framework, is a feature of the WEB platform that allows to real-time visualize the exact place where the weather data are measured

The MeteoTracker APP allows photo-capture tagged with weather data measured in that spot.

So, every MeteoTracker can be turned in a photo-album rich of weather and visual information

gallery/1569756755837
gallery/lab_test_mtwe

HIGHLIGHTS

REAL-TIME STREET-VIEW VISUALIZATION OF WEATHER DATA

DONNESDORF (GERMANY), DONAU CHILLING EFFECT, JUNE 16TH 2019

SOUTH-WEST SARDINIA, STRONG SOLAR RADIATION EXPOSURE AND ERROR CORRECTION BY MT MULTI-SENSOR

gallery/cagliari_effetto_brezza_luglio_2019_composite

CAGLIARI, SARDINIA (ITALY), STRONG TEMPERATURE VARIATION RATIO DUE TO BREEZE AND BUILDING-BLOCKING EFFECT

SOLAR RADIATION ERROR CORRECTION SYSTEM

METEO-TAGGED PHOTOS

gallery/street view_1
gallery/car2_rotated_no_bgnd
gallery/research_no_bgnd
gallery/location_no_bgnd
gallery/radiowaves_rotated_no_bgnd
gallery/line_45°
gallery/cloud_no_bgnd
gallery/pressure
gallery/humidity
gallery/2_cut_no_bg

Weather data mobile tracking system

gallery/map_cagliari_1
gallery/smart city icon_no_bkgnd
